Introduction
Can used with SKC-MA400 multi-angle fitting fusion machine or used alone.
Cut pipe in the workshop, in accordance with the angle and size of the set.to reduce the waste pipe, to fully enhance the efficiency of the production ofpipe fittings.
Can be used for cutting PE, insulation and corrugated pipe or other non-metallicmaterials.
Details
Model: SKC-MA400B
Welding Type: Variable speed band saw
Brand Name: SKC or OEM
Color: Yellow or customized
Parameter
|
Name |
Plastic pipe cutting band saw 400 |
|
Applied materials |
PE, PP ,PVDF,Corrugated pipe (configuration may be increased), heat preservation (need to modify the configuration) |
|
Welded pipe diameter ranges |
≤DN400 mm |
|
The cutting Angle |
0-67.5° |
|
Working voltage |
AC380V±10 ％ ,50Hz (Special voltage can be customized) |
|
The total power |
1.5 Kw |
|
Band saw cutting speed |
0-250m/min |
|
Cutting feed speed |
Adjustable |
|
net weight, Kilo |
9800Kg |
Features
1.Cutting feed from hydraulic power source, to ensure the stable and precision pressure was provided in the process of cutting. At the same time, the hydraulic system also adopts the advanced buffer design to make the machine running smoothly, without any impact;
2.Saw blade speed with frequency control of motor speed, to extend the service life of saw blade effectively. If the blade is broken, the machine with the functions of automatic detection and automatic stop, to guarantee the safety of operator;
3.Max Cutting Angle 0-67.5 °. Angle adjustment is convenient, easy and fast;
4.Cutting speed adopts hydraulic stepless speed change, and was equipped with a fast forward and working speed switch button;
Additive projects
The blade quick positioning device
All specifications, high precision tubing internal and external liners
Electric clamping device
Tube electric feeding device
Automatic positioning device
The PLC programmable control system
Packing and Shipping
Experience and Markets
Our factory has been in the business of making butt fusion welding machine for more than 20 years. Our chief engineer participated in the draft of Chinese butt fusion welding industry standards, and our R&D ability making us the leading company of this industry. We supplied machines to hundreds of customers worldwide, who placed repeated orders from us because of good product quality and trust in us.
Our Company
Advantages
1.We are a leading company in the butt fusion machine industry.
2.We serve customers worldwide, providing industry solutions for welding PE, PP and HDPE pipes and making pipe fittings.
3.We can print your logo or trade mark on our machines.
4.We can customize welding machines to meet your demand.
5.We can do OEM &ODM
FAQ
1. Q: How can i get the after-service?
A: We will send you the spare parts by free if the problems caused by us.
If it is the men-made problems, we also send the spare parts, however it is charged. Any problem, you can call us directly.
2. Q: Is your price competitive?
A: Only good quality machine we supply. Surely we will give you best factory price without compromising on quality and service.
