Descriptions :
Suitable for fabricating elbow, tee, cross and Y shape( 45° and 60° ) fittings of
PE.PP, PVDF in workshop.
By selecting different combinations of components, can be used for insulation and
corrugated pipe fittings.
Touch-screen with CNC control of welding cycle and data logger is standard.
Parameters
|
Name |
PE Pipe Multi angle plastic pipe fusion machine 800mm |
|
Applied materials |
PE, PP ,PVDF,Corrugated pipe (Add optional parts), heat preservation (need optional parts) |
|
Pipe types |
0-90°elbow, Tee, cross, Y shape fittings 45°or 60°, flange |
|
Pipe diameter range |
DN400-800 mm |
|
Applicable environmental temperature |
-5～45℃ |
|
Working voltage |
AC380V±10 ％ ,50Hz (Special voltage can be customized) |
|
Total power |
48Kw |
|
Temperature control range |
150℃~290℃(Digital temperature control and correction) |
|
Final temperature control precision |
±5℃ |
|
Net weight |
5100Kg |
Features:
·The heating plate configuration precise digital temperature control.
·Basic Frame more lighter and firm.
·The heating plate and planning tool use flip style, operate easy and convenient.
·Reliable chain security measures, use more secure.
·Product complies with 98/37/EC and 73/23/EEC standards.
Details
Model: SKC-MA800
Welding Type: Plastic Pipe fitting machine
Brand Name: SKC or OEM
Color: Yellow or customized
Optional parts
1. Steel outer clamps and aluminum alloy inner clamps for fabricating 45 °, 60 °, Y-shape fittings of Max. DN800mm;
2. Can add independent controller, color touch screen for recording welding process;
3. Can upgrade facer and heater control to front and back hydraulic system.
4. Can add automatic welding programs for key welding processes; (from start to finish. Need to add optional parts from the fore-mentioned points 2 or 3);
5. Add hydraulic open and close system for elbow clamps, T and cross clamps;
Malfunctions Analyzing & Solutions
Possible malfunctions and solutions are stated as below
|
Correct joint |
|
|
Bead narrow and fallen. Pressure too high. |
|
|
Small bead. Not enough pressure |
|
Application
Suitable for making elbow of any angle in workshop, such as T, cross and Y-shape fittings (45 °, 60 ° ) ; Can welding PP, PE, PVDF pipe;Through special configuration, also can welding heat insulation pipe, corrugated tube; Welding parameters comply with ISO, DVS, CEN and Chinese welding standards.
Company Overview
SAEMIN With over 30 years of expertise, SAEMIN has become a global leader in PE pipe fusion equipment manufacturing.
Our product range includes field butt fusion machines, multi-angle workshop welders, electrofusion units, specialty welding machines, and cutting systems, fully supporting PE, PP, PVDF, PPH and more.
Our solutions are widely applied in water, gas, oil, nuclear power, marine aquaculture, and shipbuilding industries.
Guided by SKC: Smart, Knowledgeable, Consistent – Every Weld, Every Time, we remain dedicated to delivering high-quality welding solutions worldwide.
Packing and Shipping
Company profile
Saemin has professional production and R&D bases in both South Korea and China. The product has dozens of patents. Saemin has won the acceptance of global users, with its excellent quality, practical performance, and close perfect after sales services. Saemin technical staff was also involved in the industry standard drafting in both South Korea nd China. The company has always been ahead of the peer companies thanks to constant products innovation.
Possible malfunctions and solutions are stated as below
|
Correct joint |
|
|
Bead narrow and fallen. Pressure too high. |
|
|
Small bead. Not enough pressure |
|
|
Groove in the center of welding bead. Not enough temperature or change-over time too long |
|
|
The materials have different heating times or heating temperatures. This may indicate the welding of PE80 and PE100 which is acceptable according to pipe and fitting manufacturers' instructions. |
|
|
Misalignment. Tolerances exceeds 10% of pipe wall thickness |
|
Services
1. Product quality control and delivery time is strictly controlled;
2. Direct manufacturing factory offering competitive price;
3. All the inquiries will be replied within 12 hours;
4. OEM & ODM service are available;
5. Providing first-class after-sales services to the customers.
FAQ
1. Q: How is your price level?
A: Factory direct sale, we have whole production line work process from platform to main parts.
2. Q: How does your factory do in the area of quality control?
A: CE certificates, one year quality warranty, and life-time Technical Support.
